kspaceFirstOrder3D-OMP  1.2
The C++ implementation of the k-wave toolbox for the time-domain simulation of acoustic wave fields in 3D
Hdf5FileHeader.h File Reference

The header file containing the class processing file headers. Detail about the file header are described below. More...

#include <map>
#include <Hdf5/Hdf5File.h>
#include <Utils/DimensionSizes.h>
#include <Utils/MatrixNames.h>
Include dependency graph for Hdf5FileHeader.h:
This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes

class  Hdf5FileHeader
 Class for HDF5 file header. More...


Detailed Description

Author
Jiri Jaros
Faculty of Information Technology
Brno University of Technology
jaros.nosp@m.jir@.nosp@m.fit.v.nosp@m.utbr.nosp@m..cz
Version
kspaceFirstOrder3D 2.16
Date
24 August 2017, 09:51 (created)
29 August 2017, 10:00 (revised)

HDF5 File Header Structure

The header includes following information

+----------------------------------------------------------------------------------------------------------------------+
|                                           Input File / Checkpoint File Header                                        |
+----------------------------------------------------------------------------------------------------------------------+
| created_by                              Short description of the tool that created this file                         |
| creation_date                           Date when the file was created                                               |
| file_description                        Short description of the content of the file (e.g. simulation name)          |
| file_type                               Type of the file (input)                                                     |
| major_version                           Major version of the file definition (1)                                     |
| minor_version                           Minor version of the file definition (1)                                     |
+----------------------------------------------------------------------------------------------------------------------+
+----------------------------------------------------------------------------------------------------------------------+
|                                                    Output File Header                                                |
+----------------------------------------------------------------------------------------------------------------------+
| created_by                              Short description of the tool that created this file                         |
| creation_date                           Date when the file was created                                               |
| file_description                        Short description of the content of the file (e.g. simulation name)          |
| file_type                               Type of the file (output)                                                    |
| major_version                           Major version of the file definition (1)                                     |
| minor_version                           Minor version of the file definition (1)                                     |
+----------------------------------------------------------------------------------------------------------------------+
| host_names                              List of hosts (computer names) the simulation was executed on                |
| number_of_cpu_cores                     Number of CPU cores used for the simulation                                  |
| data_loading_phase_execution_time       Time taken to load data from the file                                        |
| pre-processing_phase_execution_time     Time taken to pre-process data                                               |
| simulation_phase_execution_time         Time taken to run the simulation                                             |
| post-processing_phase_execution_time    Time taken to complete the post-processing phase                             |
| total_execution_time                    Total execution time                                                         |
| peak_core_memory_in_use                 Peak memory required per core during the simulation                          |
| total_memory_in_use Total               Peak memory in use                                                           |
+----------------------------------------------------------------------------------------------------------------------+

This file is part of the C++ extension of the k-Wave Toolbox.

This file is part of the k-Wave. k-Wave is free software: you can redistribute it and/or modify it under the terms of the GNU Lesser General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

k-Wave is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU Lesser General Public License for more details.

You should have received a copy of the GNU Lesser General Public License along with k-Wave. If not, see http://www.gnu.org/licenses/.

Definition in file Hdf5FileHeader.h.
