Output stream for quantities sampled by a cuboid corner sensor mask. More...

#include <CuboidOutputStream.h>

Inheritance diagram for CuboidOutputStream:

Collaboration diagram for CuboidOutputStream:

[legend]

Classes
struct	CuboidInfo
	This structure information about a HDF5 dataset (one cuboid). More...

Public Member Functions
	CuboidOutputStream ()=delete
	Default constructor not allowed.

	CuboidOutputStream (Hdf5File &file, MatrixName &groupName, const RealMatrix &sourceMatrix, const IndexMatrix &sensorMask, const ReduceOperator ReduceOp, float *bufferToReuse=nullptr)
	Constructor links the HDF5 dataset, SourceMatrix, and SensorMask together. More...

	CuboidOutputStream (const CuboidOutputStream &)=delete
	Copy constructor is not allowed.

virtual	~CuboidOutputStream ()
	Destructor. More...

CuboidOutputStream &	operator= (const CuboidOutputStream &)=delete
	operator= is not allowed.

virtual void	create ()
	Create a HDF5 stream and allocate data for it. More...

virtual void	reopen ()
	Reopen the output stream after restart and reload data. More...

virtual void	sample ()
	Sample data into buffer and apply reduction, or flush to disk - based on a sensor mask. More...

virtual void	postProcess ()
	Apply post-processing on the buffer and flush it to the file. More...

virtual void	checkpoint ()
	Checkpoint the stream and close. More...

virtual void	close ()
	Close stream (apply post-processing if necessary, flush data and close). More...

Public Member Functions inherited from BaseOutputStream
	BaseOutputStream ()=delete
	Default constructor not allowed.

	BaseOutputStream (Hdf5File &file, MatrixName &rootObjectName, const RealMatrix &sourceMatrix, const ReduceOperator reduceOp, float *bufferToReuse=nullptr)
	Constructor. More...

	BaseOutputStream (const BaseOutputStream &src)
	Copy constructor not allowed.

virtual	~BaseOutputStream ()
	Destructor. More...

BaseOutputStream &	operator= (const BaseOutputStream &src)
	Operator = not allowed (we don't want any data movements).

Protected Member Functions
virtual hid_t	createCuboidDataset (const size_t cuboidIdx)
	Create a new dataset for a given cuboid specified by index (order). More...

template<BaseOutputStream::ReduceOperator reduceOp>
void	sampleAggregated ()
	Sample aggregated values. More...

virtual void	flushBufferToFile ()
	Flush the buffer to the file. More...

Protected Member Functions inherited from BaseOutputStream
virtual void	allocateMemory ()
	Allocate memory using proper memory alignment. More...

virtual void	freeMemory ()
	Free memory. More...

Protected Attributes
const IndexMatrix &	mSensorMask
	Sensor mask to sample data.

hid_t	mGroup
	Handle to a HDF5 dataset.

std::vector< CuboidInfo >	mCuboidsInfo
	vector keeping handles and positions of all cuboids.

size_t	mSampledTimeStep
	Timestep to store (N/A for aggregated).

Protected Attributes inherited from BaseOutputStream
Hdf5File &	mFile
	Handle to HDF5 output file.

std::string	mRootObjectName
	HDF5 group/dataset in the output file where to store data in.

const RealMatrix &	mSourceMatrix
	Source matrix to be sampled.

const ReduceOperator	mReduceOp
	Reduction operator.

bool	mBufferReuse
	if true, the container reuses another matrix as scratch place, e.g. Temp_1_RS3D, Temp_2_RS3D, Temp_3_RS3D.

size_t	mBufferSize
	Buffer size.

float *	mStoreBuffer
	Temporary buffer for store - only if Buffer Reuse = false!

Additional Inherited Members
Public Types inherited from BaseOutputStream
enum	ReduceOperator { ReduceOperator::kNone, ReduceOperator::kRms, ReduceOperator::kMax, ReduceOperator::kMin }
	How to aggregate data. More...

Static Protected Attributes inherited from BaseOutputStream
static constexpr size_t	kChunkSize4MB = 1048576
	chunk size of 4MB in number of float elements.

Detailed Description

Output stream for quantities sampled by a cuboid corner sensor mask. This class writes data into separated datasets (one per cuboid) under a given dataset in the HDF5 file (time-series as well as aggregations).

Definition at line 49 of file CuboidOutputStream.h.

Constructor & Destructor Documentation

◆ CuboidOutputStream()

CuboidOutputStream::CuboidOutputStream	(	Hdf5File &	file,
		MatrixName &	groupName,
		const RealMatrix &	sourceMatrix,
		const IndexMatrix &	sensorMask,
		const ReduceOperator	reduceOp,
		float *	bufferToReuse = `nullptr`
	)

Parameters

[in]	file	- HDF5 file to write the output to.
[in]	groupName	- The name of the HDF5 group. This group contains datasets for particular cuboids.
[in]	sourceMatrix	- Source matrix to be sampled.
[in]	sensorMask	- Sensor mask with the cuboid coordinates.
[in]	reduceOp	- Reduction operator.
[in]	bufferToReuse	- If there is a memory space to be reused, provide a pointer.

Constructor - links the HDF5 dataset, SourceMatrix, and SensorMask together.

Definition at line 50 of file CuboidOutputStream.cpp.

◆ ~CuboidOutputStream()

CuboidOutputStream::~CuboidOutputStream ( )

virtual

If the file is still opened, it applies the post processing and flush the data. Then, the object memory is freed and the object destroyed.

Destructor.

Definition at line 68 of file CuboidOutputStream.cpp.

Member Function Documentation

◆ checkpoint()

void CuboidOutputStream::checkpoint ( )

virtual

Checkpoint the stream.

Implements BaseOutputStream.

Definition at line 253 of file CuboidOutputStream.cpp.

◆ close()

void CuboidOutputStream::close ( )

virtual

Close stream (apply post-processing if necessary, flush data, close datasets and the group).

Implements BaseOutputStream.

Definition at line 263 of file CuboidOutputStream.cpp.

◆ create()

void CuboidOutputStream::create ( )

virtual

Create a HDF5 stream and allocate data for it. It also creates a HDF5 group with particular datasets (one per cuboid).

Implements BaseOutputStream.

Definition at line 81 of file CuboidOutputStream.cpp.

◆ createCuboidDataset()

hid_t CuboidOutputStream::createCuboidDataset ( const size_t cuboidIdx )

protectedvirtual

Parameters

[in] cuboidIdx - Index of the cuboid in the sensor mask.

Returns: Handle to the HDF5 dataset.

Create a new dataset for a given cuboid specified by index (order).

Definition at line 289 of file CuboidOutputStream.cpp.

◆ flushBufferToFile()

void CuboidOutputStream::flushBufferToFile ( )

protectedvirtual

Flush the buffer to the file (to multiple datasets if necessary).

Definition at line 408 of file CuboidOutputStream.cpp.

◆ postProcess()

void CuboidOutputStream::postProcess ( )

virtual

Apply post-processing on the buffer and flush it to the file.

Reimplemented from BaseOutputStream.

Definition at line 241 of file CuboidOutputStream.cpp.

◆ reopen()

void CuboidOutputStream::reopen ( )

virtual

Reopen the output stream after restart and reload data.

Implements BaseOutputStream.

Definition at line 119 of file CuboidOutputStream.cpp.

◆ sample()

void CuboidOutputStream::sample ( )

virtual

Sample data into buffer and apply reduction, or flush to disk - based on a sensor mask.

Implements BaseOutputStream.

Definition at line 186 of file CuboidOutputStream.cpp.

◆ sampleAggregated()

template<BaseOutputStream::ReduceOperator reduceOp>

void CuboidOutputStream::sampleAggregated ( )

protected

Template Parameters

reduceOp - Reduction operator

Sample aggregated values.

Definition at line 339 of file CuboidOutputStream.cpp.

The documentation for this class was generated from the following files:

OutputStreams/CuboidOutputStream.h
OutputStreams/CuboidOutputStream.cpp
