Abstract base class for output data streams (sampled data). More...

#include <BaseOutputStream.h>

Inheritance diagram for BaseOutputStream:

Collaboration diagram for BaseOutputStream:

[legend]

Public Types
enum	ReduceOperator { ReduceOperator::kNone, ReduceOperator::kRms, ReduceOperator::kMax, ReduceOperator::kMin }
	How to aggregate data. More...

Public Member Functions
	BaseOutputStream ()=delete
	Default constructor not allowed.

	BaseOutputStream (Hdf5File &file, MatrixName &rootObjectName, const RealMatrix &sourceMatrix, const ReduceOperator reduceOp, float *bufferToReuse=nullptr)
	Constructor. More...

	BaseOutputStream (const BaseOutputStream &src)
	Copy constructor not allowed.

virtual	~BaseOutputStream ()
	Destructor. More...

BaseOutputStream &	operator= (const BaseOutputStream &src)
	Operator = not allowed (we don't want any data movements).

virtual void	create ()=0
	Create a HDF5 stream and allocate data for it.

virtual void	reopen ()=0
	Reopen the output stream after restart.

virtual void	sample ()=0
	Sample data into buffer, apply reduction or flush to disk - based on a sensor mask.

virtual void	postProcess ()
	Apply post-processing on the buffer and flush it to the file. More...

virtual void	checkpoint ()=0
	Checkpoint the stream.

virtual void	close ()=0
	Close stream (apply post-processing if necessary, flush data and close).

Protected Member Functions
virtual void	allocateMemory ()
	Allocate memory using proper memory alignment. More...

virtual void	freeMemory ()
	Free memory. More...

Protected Attributes
Hdf5File &	mFile
	Handle to HDF5 output file.

std::string	mRootObjectName
	HDF5 group/dataset in the output file where to store data in.

const RealMatrix &	mSourceMatrix
	Source matrix to be sampled.

const ReduceOperator	mReduceOp
	Reduction operator.

bool	mBufferReuse
	if true, the container reuses another matrix as scratch place, e.g. Temp_1_RS3D, Temp_2_RS3D, Temp_3_RS3D.

size_t	mBufferSize
	Buffer size.

float *	mStoreBuffer
	Temporary buffer for store - only if Buffer Reuse = false!

Static Protected Attributes
static constexpr size_t	kChunkSize4MB = 1048576
	chunk size of 4MB in number of float elements.

Detailed Description

Data are sampled based on the the sensor mask and the reduction operator. The sampled data is stored in the output HDF5 file.

Definition at line 47 of file BaseOutputStream.h.

Member Enumeration Documentation

◆ ReduceOperator

enum BaseOutputStream::ReduceOperator

strong

Enumerator
kNone	Store actual data (time series).
kRms	Calculate root mean square.
kMax	Store maximum.
kMin	Store minimum.

Definition at line 55 of file BaseOutputStream.h.

Constructor & Destructor Documentation

◆ BaseOutputStream()

BaseOutputStream::BaseOutputStream	(	Hdf5File &	file,
		MatrixName &	rootObjectName,
		const RealMatrix &	sourceMatrix,
		const ReduceOperator	reduceOp,
		float *	bufferToReuse = `nullptr`
	)

There is no sensor mask by default to support both sensor mask and whole domain sampling. The constructor links the HDF5 dataset, source (sampled matrix) and the reduction operator together. The constructor DOES NOT allocate memory because the size of the sensor mask is not known at the time the instance of the class is being created.

Parameters

[in]	file	- Handle to the output HDF5 file.
[in]	rootObjectName	- The root object that stores the sample data (dataset or group).
[in]	sourceMatrix	- The source matrix (only real matrices are supported).
[in]	reduceOp	- Reduction operator.
[in]	bufferToReuse	- An external buffer can be used to line up the grid points.

Constructor - there is no sensor mask by default!

Definition at line 52 of file BaseOutputStream.cpp.

◆ ~BaseOutputStream()

virtual BaseOutputStream::~BaseOutputStream ( )

inlinevirtual

If the file is still opened, it applies the post processing and flush the data. Then, the object memory is freed and the object destroyed.

Definition at line 98 of file BaseOutputStream.h.

Member Function Documentation

◆ allocateMemory()

void BaseOutputStream::allocateMemory ( )

protectedvirtual

Exceptions

std::bad_alloc - If there's not enough memory.

Warning: This can routine is not used in the base class (should be used in derived ones).

Allocate memory using a proper memory alignment.

Definition at line 117 of file BaseOutputStream.cpp.

◆ freeMemory()

void BaseOutputStream::freeMemory ( )

protectedvirtual

Warning: This can routine is not used in the base class (should be used in derived ones).

Free memory.

Definition at line 179 of file BaseOutputStream.cpp.

◆ postProcess()

void BaseOutputStream::postProcess ( )

virtual

Apply post-processing on the buffer. It supposes the elements are independent.

Reimplemented in CuboidOutputStream, IndexOutputStream, and WholeDomainOutputStream.

Definition at line 72 of file BaseOutputStream.cpp.

The documentation for this class was generated from the following files:

OutputStreams/BaseOutputStream.h
OutputStreams/BaseOutputStream.cpp
