Output stream for quantities sampled by an index sensor mask. More...

#include <IndexOutputStream.h>

Inheritance diagram for IndexOutputStream:

Collaboration diagram for IndexOutputStream:

[legend]

Public Member Functions
	IndexOutputStream ()=delete
	Default constructor not allowed.

	IndexOutputStream (Hdf5File &file, MatrixName &datasetName, const RealMatrix &sourceMatrix, const IndexMatrix &sensorMask, const ReduceOperator reduceOp, float *bufferToReuse=nullptr)
	Constructor links the HDF5 dataset, SourceMatrix, and SensorMask together. More...

	IndexOutputStream (const IndexOutputStream &)=delete
	Copy constructor not allowed.

virtual	~IndexOutputStream ()
	Destructor. More...

virtual void	create ()
	Create a HDF5 stream and allocate data for it. More...

virtual void	reopen ()
	Reopen the output stream after restart and reload data. More...

virtual void	sample ()
	Sample data into buffer, apply reduction or flush to disk - based on a sensor mask. More...

virtual void	postProcess ()
	Apply post-processing on the buffer and flush it to the file. More...

virtual void	checkpoint ()
	Checkpoint the stream. More...

virtual void	close ()
	Close stream (apply post-processing if necessary, flush data and close). More...

Public Member Functions inherited from BaseOutputStream
	BaseOutputStream ()=delete
	Default constructor not allowed.

	BaseOutputStream (Hdf5File &file, MatrixName &rootObjectName, const RealMatrix &sourceMatrix, const ReduceOperator reduceOp, float *bufferToReuse=nullptr)
	Constructor. More...

	BaseOutputStream (const BaseOutputStream &src)
	Copy constructor not allowed.

virtual	~BaseOutputStream ()
	Destructor. More...

BaseOutputStream &	operator= (const BaseOutputStream &src)
	Operator = not allowed (we don't want any data movements).

Protected Member Functions
virtual void	flushBufferToFile ()
	Flush the buffer to the file. More...

Protected Member Functions inherited from BaseOutputStream
virtual void	allocateMemory ()
	Allocate memory using proper memory alignment. More...

virtual void	freeMemory ()
	Free memory. More...

Protected Attributes
const IndexMatrix &	sensorMask
	Sensor mask to sample data.

hid_t	mDataset
	Handle to a HDF5 dataset.

size_t	mSampledTimeStep
	Time step to store (N/A for aggregated).

Protected Attributes inherited from BaseOutputStream
Hdf5File &	mFile
	Handle to HDF5 output file.

std::string	mRootObjectName
	HDF5 group/dataset in the output file where to store data in.

const RealMatrix &	mSourceMatrix
	Source matrix to be sampled.

const ReduceOperator	mReduceOp
	Reduction operator.

bool	mBufferReuse
	if true, the container reuses another matrix as scratch place, e.g. Temp_1_RS3D, Temp_2_RS3D, Temp_3_RS3D.

size_t	mBufferSize
	Buffer size.

float *	mStoreBuffer
	Temporary buffer for store - only if Buffer Reuse = false!

Additional Inherited Members
Public Types inherited from BaseOutputStream
enum	ReduceOperator { ReduceOperator::kNone, ReduceOperator::kRms, ReduceOperator::kMax, ReduceOperator::kMin }
	How to aggregate data. More...

Static Protected Attributes inherited from BaseOutputStream
static constexpr size_t	kChunkSize4MB = 1048576
	chunk size of 4MB in number of float elements.

Detailed Description

Output stream for quantities sampled by an index sensor mask. This class writes data to a single dataset in a root group of the HDF5 file (time-series as well as aggregations).

Definition at line 44 of file IndexOutputStream.h.

Constructor & Destructor Documentation

◆ IndexOutputStream()

IndexOutputStream::IndexOutputStream	(	Hdf5File &	file,
		MatrixName &	datasetName,
		const RealMatrix &	sourceMatrix,
		const IndexMatrix &	sensorMask,
		const ReduceOperator	reduceOp,
		float *	bufferToReuse = `nullptr`
	)

Constructor - links the HDF5 dataset, source (sampled matrix), Sensor mask and the reduction operator together. The constructor DOES NOT allocate memory because the size of the sensor mask is not known at the time the instance of the class is being created.

Parameters

[in]	file	- Handle to the HDF5 (output) file.
[in]	datasetName	- The dataset's name (index based sensor data is store in a single dataset).
[in]	sourceMatrix	- The source matrix (only real matrices are supported).
[in]	sensorMask	- Index based sensor mask.
[in]	reduceOp	- Reduction operator.
[in]	bufferToReuse	- An external buffer can be used to line up the grid points.

Constructor - links the HDF5 dataset, SourceMatrix, and SensorMask together.

Definition at line 52 of file IndexOutputStream.cpp.

◆ ~IndexOutputStream()

IndexOutputStream::~IndexOutputStream ( )

virtual

If the file is still opened, it applies the post processing and flush the data. Then, the object memory is freed and the object destroyed.

Destructor.

Definition at line 70 of file IndexOutputStream.cpp.

Member Function Documentation

◆ checkpoint()

void IndexOutputStream::checkpoint ( )

virtual

Checkpoint the stream and close.

Implements BaseOutputStream.

Definition at line 244 of file IndexOutputStream.cpp.

◆ close()

void IndexOutputStream::close ( )

virtual

Close stream (apply post-processing if necessary, flush data and close).

Implements BaseOutputStream.

Definition at line 257 of file IndexOutputStream.cpp.

◆ create()

void IndexOutputStream::create ( )

virtual

Create a HDF5 stream, create a dataset, and allocate data for it.

Implements BaseOutputStream.

Definition at line 81 of file IndexOutputStream.cpp.

◆ flushBufferToFile()

void IndexOutputStream::flushBufferToFile ( )

protectedvirtual

Flush the buffer down to the file at the actual position.

Definition at line 278 of file IndexOutputStream.cpp.

◆ postProcess()

void IndexOutputStream::postProcess ( )

virtual

Apply post-processing on the buffer and flush it to the file.

Reimplemented from BaseOutputStream.

Definition at line 229 of file IndexOutputStream.cpp.

◆ reopen()

void IndexOutputStream::reopen ( )

virtual

Reopen the output stream after restart.

Implements BaseOutputStream.

Definition at line 127 of file IndexOutputStream.cpp.

◆ sample()

void IndexOutputStream::sample ( )

virtual

Sample grid points, line them up in the buffer an flush to the disk unless a reduction operator is applied.

Implements BaseOutputStream.

Definition at line 165 of file IndexOutputStream.cpp.

The documentation for this class was generated from the following files:

OutputStreams/IndexOutputStream.h
OutputStreams/IndexOutputStream.cpp
