kspaceFirstOrder3D-OMP
1.1
The C++ implementation of the k-wave toolbox for the time-domain simulation of acoustic wave fields in 3D
|
Abstract base class for output data streams (sampled data). More...
#include <OutputHDF5Stream.h>
Public Types | |
enum | TReductionOperator { roNONE, roRMS, roMAX, roMIN } |
How to aggregate data. More... | |
Public Member Functions | |
TBaseOutputHDF5Stream (THDF5_File &HDF5_File, const char *HDF5_RootObjectName, const TRealMatrix &SourceMatrix, const TReductionOperator ReductionOp, float *BufferToReuse=NULL) | |
Constructor - there is no sensor mask by default! More... | |
virtual | ~TBaseOutputHDF5Stream () |
Destructor. More... | |
virtual void | Create ()=0 |
Create a HDF5 stream and allocate data for it. | |
virtual void | Reopen ()=0 |
Reopen the output stream after restart. | |
virtual void | Sample ()=0 |
Sample data into buffer, apply reduction or flush to disk - based on a sensor mask. | |
virtual void | PostProcess () |
Apply post-processing on the buffer and flush it to the file. More... | |
virtual void | Checkpoint ()=0 |
Checkpoint the stream. | |
virtual void | Close ()=0 |
Close stream (apply post-processing if necessary, flush data and close). | |
Protected Member Functions | |
TBaseOutputHDF5Stream () | |
Default constructor not allowed. | |
TBaseOutputHDF5Stream (const TBaseOutputHDF5Stream &src) | |
Copy constructor not allowed. | |
TBaseOutputHDF5Stream & | operator= (const TBaseOutputHDF5Stream &src) |
Operator = not allowed (we don't want any data movements). | |
virtual void | AllocateMemory () |
A generic function to allocate memory - not used in the base class. More... | |
virtual void | FreeMemory () |
A generic function to free memory - not used in the base class. More... | |
Protected Attributes | |
THDF5_File & | HDF5_File |
HDF5 file handle. | |
char * | HDF5_RootObjectName |
Dataset name. | |
const TRealMatrix & | SourceMatrix |
Source matrix to be sampled. | |
const TReductionOperator | ReductionOp |
Reduction operator. | |
bool | BufferReuse |
if true, the container reuses e.g. Temp_1_RS3D, Temp_2_RS3D, Temp_3_RS3D. | |
size_t | BufferSize |
Buffer size. | |
float * | StoreBuffer |
Temporary buffer for store - only if Buffer Reuse = false! | |
Static Protected Attributes | |
static const size_t | ChunkSize_4MB = 1048576 |
chunk size of 4MB in number of float elements. | |
static const size_t | MinGridpointsToSampleInParallel = 1048576 |
The minimum number of elements to start sampling in parallel (4MB). | |
Abstract base class for output data streams (sampled data).
Definition at line 55 of file OutputHDF5Stream.h.
How to aggregate data
roNONE - store actual data (time series) roRMS - calculate root mean square
roMAX - store maximum roMIN - store minimum
Definition at line 68 of file OutputHDF5Stream.h.
|
inline |
Constructor - there is no sensor mask by default! it links the HDF5 dataset, source (sampled matrix) and the reduction operator together. The constructor DOES NOT allocate memory because the size of the sensor mask is not known at the time the instance of the class is being created.
[in] | HDF5_File | - Handle to the HDF5 (output) file |
[in] | HDF5_RootObjectName | - The root object that stores the sample data (dataset or group) |
[in] | SourceMatrix | - The source matrix (only real matrices are supported) |
[in] | ReductionOp | - Reduction operator |
[in] | BufferToReuse | - An external buffer can be used to line up the grid points |
Definition at line 90 of file OutputHDF5Stream.h.
|
inlinevirtual |
Destructor.
Definition at line 112 of file OutputHDF5Stream.h.
|
protectedvirtual |
Allocate memory using a proper memory alignment.
Definition at line 119 of file OutputHDF5Stream.cpp.
|
protectedvirtual |
Free memory.
Definition at line 184 of file OutputHDF5Stream.cpp.
|
virtual |
Apply post-processing on the buffer. It supposes the elements are independent.
Reimplemented in TWholeDomainOutputHDF5Stream, TCuboidOutputHDF5Stream, and TIndexOutputHDF5Stream.
Definition at line 68 of file OutputHDF5Stream.cpp.
