Class implementing the matrix container. More...

#include <MatrixContainer.h>

Collaboration diagram for TMatrixContainer:

Public Member Functions
	TMatrixContainer ()
	Constructor.

virtual	~TMatrixContainer ()
	Destructor. More...

size_t	size () const
	Get number of matrices in the container. More...

bool	empty () const
	Is the container empty? More...

void	CreateAllObjects ()
	Create instances of all objects in the container. More...

void	LoadDataFromInputHDF5File (THDF5_File &HDF5_File)
	Load all matrices from the HDF5 file. More...

void	LoadDataFromCheckpointHDF5File (THDF5_File &HDF5_File)
	Load all matrices from the HDF5 file. More...

void	StoreDataIntoCheckpointHDF5File (THDF5_File &HDF5_File)
	Store selected matrices into the checkpoint file. More...

void	FreeAllMatrices ()
	Free all matrices - destroy them. More...

void	AddMatricesIntoContainer ()
	Set all matrices recored - populate the container. More...

TMatrixRecord &	GetMatrixRecord (const TMatrixID MatrixID)
	Get matrix record (data and information). More...

TMatrixRecord &	operator[] (const TMatrixID MatrixID)
	operator []. More...

template<typename T >
T &	GetMatrix (const TMatrixID MatrixID)
	Get the matrix with a specific type from the container. More...

Private Types
typedef map< TMatrixID, TMatrixRecord >	TMatrixRecordContainer
	Datatype for map associating the matrix ID enum and matrix record.

Private Member Functions
	TMatrixContainer (const TMatrixContainer &src)
	Copy constructor is not allowed for public.

TMatrixContainer &	operator= (const TMatrixContainer &src)
	Operator = is not allowed for public.

void	PrintErrorAndThrowException (const char FMT, const string HDF5MatrixName, const char File, const int Line)
	Print error and throw an exception. More...

Private Attributes
TMatrixRecordContainer	MatrixContainer
	Map holding the container.

Detailed Description

This container is responsible to maintain all the matrices in the code except the output streams. The matrices are allocated, freed, loaded stored and checkpointed from here.

Definition at line 165 of file MatrixContainer.h.

Constructor & Destructor Documentation

TMatrixContainer::~TMatrixContainer ( )

virtual

Destructor of TMatrixContainer.

Definition at line 144 of file MatrixContainer.cpp.

Member Function Documentation

void TMatrixContainer::AddMatricesIntoContainer ( )

This function defines common matrices in K-Wave. All matrices records are created here.

Definition at line 287 of file MatrixContainer.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

void TMatrixContainer::CreateAllObjects ( )

Create all matrix objects in the container.

Exceptions

errors cause an exception bad_alloc.

Definition at line 155 of file MatrixContainer.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

bool TMatrixContainer::empty ( ) const

inline

Is the container empty?

Returns: true if the container is empty

Definition at line 189 of file MatrixContainer.h.

void TMatrixContainer::FreeAllMatrices ( )

Free all matrix objects.

Definition at line 267 of file MatrixContainer.cpp.

Here is the caller graph for this function:

template<typename T >

T& TMatrixContainer::GetMatrix ( const TMatrixID MatrixID )

inline

This template routine returns the reference to the matrix recasted to the specific class.

Parameters

[in] MatrixID - Matrix identifier

Returns: Base Matrix

Definition at line 240 of file MatrixContainer.h.

Here is the caller graph for this function:

TMatrixRecord& TMatrixContainer::GetMatrixRecord ( const TMatrixID MatrixID )

inline

Get matrix record (data and information).

Parameters

[in] MatrixID - Matrix identifier

Returns: the matrix record.

Definition at line 216 of file MatrixContainer.h.

void TMatrixContainer::LoadDataFromCheckpointHDF5File ( THDF5_File & HDF5_File )

Load selected matrices from checkpoint HDF5 file.

Parameters

[in] HDF5_File - HDF5 file handle

Definition at line 232 of file MatrixContainer.cpp.

Here is the caller graph for this function:

void TMatrixContainer::LoadDataFromInputHDF5File ( THDF5_File & HDF5_File )

Load all marked matrices from the HDF5 file.

Parameters

[in] HDF5_File - HDF5 file handle

Definition at line 215 of file MatrixContainer.cpp.

Here is the caller graph for this function:

TMatrixRecord& TMatrixContainer::operator[] ( const TMatrixID MatrixID )

inline

operator [].

Parameters

[in] MatrixID - Matrix identifier

Returns: the matrix record.

Definition at line 227 of file MatrixContainer.h.

void TMatrixContainer::PrintErrorAndThrowException	(	const char *	FMT,
		const string	HDF5MatrixName,
		const char *	File,
		const int	Line
	)

private

Print error and and throw an exception.

Exceptions

bad_alloc

Parameters

[in]	FMT	- format of error
[in]	HDF5MatrixName	- HDF5 dataset name
[in]	File	- File of error
[in]	Line	- Line of error

Definition at line 585 of file MatrixContainer.cpp.

Here is the caller graph for this function:

size_t TMatrixContainer::size ( ) const

inline

Get number of matrices in the container.

Returns: number of matrices in the container.

Definition at line 179 of file MatrixContainer.h.

void TMatrixContainer::StoreDataIntoCheckpointHDF5File ( THDF5_File & HDF5_File )

Store selected matrices into the checkpoint file.

Parameters

[in] HDF5_File

Definition at line 248 of file MatrixContainer.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

The documentation for this class was generated from the following files:

MatrixClasses/MatrixContainer.h
MatrixClasses/MatrixContainer.cpp
