TDimensionSizes Struct Reference

Structure with 4D dimension sizes (3 in space and 1 in time). More...

#include <DimensionSizes.h>

Public Member Functions
	TDimensionSizes ()
	Default constructor.
	TDimensionSizes (const size_t x, const size_t y, const size_t z, const size_t t=0)
	Constructor. More...
size_t	GetElementCount () const
	Get element count, in 3D only spatial domain, in 4D with time. More...
bool	Is3D () const
	Is it a 3D object?
bool	Is4D () const
	Is it a 3D object with time?
bool	operator== (const TDimensionSizes &other) const
	Operator ==. More...
bool	operator!= (const TDimensionSizes &other) const
	Operator !=. More...

Public Attributes
size_t	X
	X dimension size.
size_t	Y
	Y dimension size.
size_t	Z
	Z dimension size.
size_t	T
	Number of time steps (for time series datasets).

Friends
TDimensionSizes	operator- (const TDimensionSizes &op1, const TDimensionSizes &op2)
	Operator -. More...

Detailed Description

Structure with 4D dimension sizes (3 in space and 1 in time). The structure can be used for 3D (the time is then set to 1).
The structure contains only POD, so no C++ stuff is necessary.

Definition at line 63 of file DimensionSizes.h.

Constructor & Destructor Documentation

TDimensionSizes::TDimensionSizes ( const size_t  x, const size_t  y, const size_t  z, const size_t  t = 0  )

inline

Parameters

[in]

x,y,z,t

- Three spatial dimesnions and time.

Definition at line 81 of file DimensionSizes.h.

Member Function Documentation

size_t TDimensionSizes::GetElementCount ( ) const

inline

Get element count, in 3D only spatial domain, in 4D with time.

Returns

spatial element count or number of elements over time.

Definition at line 93 of file DimensionSizes.h.

Here is the caller graph for this function:

bool TDimensionSizes::operator!= ( const TDimensionSizes &  other ) const

inline

Parameters

[in]

other

- the second operand to compare with

Returns

true if !=

Definition at line 126 of file DimensionSizes.h.

bool TDimensionSizes::operator== ( const TDimensionSizes &  other ) const

inline

Parameters

[in]

other

- the second operand to compare with

Returns

true if ==

Definition at line 116 of file DimensionSizes.h.

Friends And Related Function Documentation

TDimensionSizes operator- ( const TDimensionSizes &  op1, const TDimensionSizes &  op2  )

friend

Get the size of the cube by subtracting two corners

Parameters

[in]	op1	- usually bottom right corner
[in]	op2	- usually top left corner

Returns

the size of the inner cuboid

Definition at line 138 of file DimensionSizes.h.

---

The documentation for this struct was generated from the following file:

• Utils/DimensionSizes.h
