TBaseFloatMatrix Class Reference

Abstract base class for float based matrices defining basic interface. Higher dimensional matrices stored as 1D arrays, row-major order. More...

#include <BaseFloatMatrix.h>

Inheritance diagram for TBaseFloatMatrix:

Collaboration diagram for TBaseFloatMatrix:

Public Member Functions
	TBaseFloatMatrix ()
	Default constructor.
virtual TDimensionSizes	GetDimensionSizes () const
	Get dimension sizes of the matrix.
virtual size_t	GetTotalElementCount () const
	Get element count of the matrix.
virtual size_t	GetTotalAllocatedElementCount () const
	Get total allocated element count (might differ from total element count used for the simulation because of padding).
virtual	~TBaseFloatMatrix ()
	Destructor.
virtual void	CopyData (const TBaseFloatMatrix &src)
	Copy data from other matrix with the same size. More...
virtual void	ZeroMatrix ()
	Zero all elements of the matrix (NUMA first touch). More...
virtual void	ScalarDividedBy (const float scalar)
	Divide scalar/ matrix_element[i]. More...
virtual float *	GetRawData ()
	Get raw data out of the class (for direct kernel access).
virtual const float *	GetRawData () const
	Get raw data out of the class (for direct kernel access).
Public Member Functions inherited from TBaseMatrix
	TBaseMatrix ()
	Default constructor.
virtual void	ReadDataFromHDF5File (THDF5_File &HDF5_File, const char *MatrixName)=0
	Read matrix from the HDF5 file. More...
virtual void	WriteDataToHDF5File (THDF5_File &HDF5_File, const char *MatrixName, const size_t CompressionLevel)=0
	Write data into the HDF5 file. More...
virtual	~TBaseMatrix ()
	Destructor.

Protected Member Functions
virtual void	AllocateMemory ()
	Memory allocation. More...
virtual void	FreeMemory ()
	Memory deallocation. More...
	TBaseFloatMatrix (const TBaseFloatMatrix &src)
	Copy constructor is not directly allowed.
TBaseFloatMatrix &	operator= (const TBaseFloatMatrix &src)
	operator = is not directly allowed.

Protected Attributes
size_t	pTotalElementCount
	Total number of elements.
size_t	pTotalAllocatedElementCount
	Total number of allocated elements (in terms of floats).
struct TDimensionSizes	pDimensionSizes
	Dimension sizes.
size_t	pDataRowSize
	Size of a 1D row in X dimension.
size_t	p2DDataSliceSize
	Size of a 2D slab (X,Y).
float *	pMatrixData
	Raw matrix data.

Detailed Description

Abstract base class for float based matrices defining basic interface. Higher dimensional matrices stored as 1D arrays, row-major order.

Definition at line 52 of file BaseFloatMatrix.h.

Member Function Documentation

void TBaseFloatMatrix::AllocateMemory ( )

protectedvirtual

Memory allocation based on the total number of elements.
Memory is aligned by the DATA_ALIGNMENT and all elements are zeroed.

Reimplemented in TFFTWComplexMatrix.

Definition at line 115 of file BaseFloatMatrix.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

void TBaseFloatMatrix::CopyData ( const TBaseFloatMatrix &  src )

virtual

Copy data from another matrix with same size.

Parameters

[in]

src

- source matrix

Definition at line 66 of file BaseFloatMatrix.cpp.

Here is the caller graph for this function:

void TBaseFloatMatrix::FreeMemory ( )

protectedvirtual

Free memory.

Reimplemented in TFFTWComplexMatrix.

Definition at line 135 of file BaseFloatMatrix.cpp.

Here is the caller graph for this function:

void TBaseFloatMatrix::ScalarDividedBy ( const float  scalar )

virtual

Divide a scalar by the elements of matrix.

Parameters

[in]

scalar

- scalar to be divided

Definition at line 94 of file BaseFloatMatrix.cpp.

Here is the caller graph for this function:

void TBaseFloatMatrix::ZeroMatrix ( )

virtual

Zero all allocated elements in parallel.
Also work as the first touch strategy on NUMA machines

Definition at line 78 of file BaseFloatMatrix.cpp.

Here is the caller graph for this function:

---

The documentation for this class was generated from the following files:

• MatrixClasses/BaseFloatMatrix.h
• MatrixClasses/BaseFloatMatrix.cpp
